Fish Inshore and Offshore with a Saltwater-Ready Spinning Reel
Hard-fighting saltwater fish put a spinning reel's gearing, body, drag, and sealing under serious load. The Shimano Saragosa SW A combines a rigid HAGANE Body and HAGANE Gear with Infinity Drive, a waterproof Cross Carbon drag, and extensive water-resistant protection for demanding inshore and offshore fishing.
Built for Heavy-Duty Saltwater Fishing
- ✅ Infinity Drive reduces rotational resistance to help the reel continue winding efficiently under heavy loads
- ✅ Rigid metal HAGANE Body helps limit reel-body flex so cranking input is transferred efficiently through the drivetrain
- ✅ Cold-forged HAGANE Gear provides the strength and durability needed for repeated saltwater use
- ✅ IPX8-rated waterproof body, X-Shield, and X-Protect provide multiple layers of water-resistant protection for demanding saltwater environments
- ✅ Waterproof Cross Carbon drag provides smooth, durable drag performance when fighting powerful fish
- ✅ Eight models from 5000XG through 25000 provide different combinations of capacity, retrieve speed, drag, and reel weight for varied inshore and offshore applications
| Model |
Gear Ratio |
Max Drag |
PowerPro Capacity (lb-yd) |
Retrieve/Crank |
Bearings |
Weight |
| SRG5000SWAXG |
6.2:1 |
22 lb |
20-245, 30-225, 40-175 |
41 in |
5/1 |
15.9 oz |
| SRG6000SWAHG |
5.7:1 |
22 lb |
30-295, 50-195, 65-140 |
41 in |
5/1 |
16 oz |
| SRG8000SWAHG |
5.6:1 |
35 lb |
40-340, 50-265, 65-215 |
42 in |
5/1 |
23.8 oz |
| SRG10000SWAPG |
4.9:1 |
33 lb |
50-360, 65-290, 80-215 |
40 in |
5/1 |
24.3 oz |
| SRG14000SWAXG |
6.2:1 |
33 lb |
50-400, 65-315, 80-240 |
53 in |
5/1 |
24.7 oz |
| SRG18000SWAHG |
5.7:1 |
49 lb |
50-600, 65-440, 80-360 |
51 in |
6/1 |
32.3 oz |
| SRG20000SWAPG |
4.4:1 |
49 lb |
65-490, 80-400, 100-340 |
41 in |
6/1 |
33 oz |
| SRG25000SWA |
4.4:1 |
44 lb |
65-630, 80-520, 100-440 |
45 in |
6/1 |
33.9 oz |
Real-World Performance
The Saragosa SW A lineup covers applications ranging from inshore casting to offshore jigging and heavy saltwater work. Faster XG and HG models provide higher retrieve rates, while PG models trade speed for lower gearing. Shimano specifically positions the series for applications including jigging for bottom fish and casting baits, making model selection important when matching the reel to your rod, line, and fishing style.
Match the Saragosa to Your Saltwater Setup
Choose the size and gear ratio that fit your line requirements and application, then build the rod-and-reel setup around the kind of saltwater fishing you plan to do.
Frequently Asked Questions About the Shimano Saragosa SW A
Is the Shimano Saragosa SW A made for saltwater fishing?
Yes. Shimano classifies the Saragosa SW A as a saltwater spinning reel and equips it with an IPX8-rated waterproof body, X-Shield, X-Protect, and a waterproof Cross Carbon drag.
Which Shimano Saragosa SW A size should I choose?
Choose according to your rod, line requirements, retrieve needs, and fishing application. The lineup runs from the 5000XG to the 25000, with substantial differences in line capacity, weight, maximum drag, gear ratio, and retrieve rate.
What is the difference between XG, HG, and PG Saragosa models?
The designations identify different gearing within the lineup: XG models use higher gear ratios and faster retrieves, HG models provide high-speed gearing, and PG models use lower gear ratios. Compare the exact gear ratio and inches retrieved per crank when selecting a model.
Can the Saragosa SW A be used for jigging?
Yes. Shimano specifically identifies jigging for bottom fish as one of the Saragosa SW A's intended saltwater applications.
What does Infinity Drive do on the Saragosa SW A?
Infinity Drive uses a low-friction main-shaft support structure and additional processing to reduce rotational resistance. Its purpose is to make the reel easier to wind under heavy loads.
